NETUM DS7100 2D Wired Handheld Auto Barcode Scanner

Features:

Auto-sensing Mode : Automatically scans barcode when put it in front of scanning window
Strong Decoding Ability : Support main 1D, 2D bar code scanning, not only printed barcodes, but also barcodes from the screen.
Compact but durable: Long life battery life up to 40 hours per battery charge. NETUM DS7100 incorporat-ed with rugged design for protection against dust and moisture. Built-in long lifecycle trigger of 10 million times guarantees a continuous productivity for best reliability

Specifications:

Optical property

lmaging Sensor: CMOS
Resolution: 640X480,Global Exposure
lllumination: (Aimer) Red color LED(lllumination) White color LED
Scan Mode:Image Scanning
Precision: 1D≥4mil 2D≥6.8mil
Print Contrast: ≥20%

Operating Characteristic

Operating Environment: -10°C-50°C
Storage Environment: -20°C-70°C
Operating Humidity: 5%-95% (No Condensation)
Ambient Illumination: 60000 Ix

Electrical Specification

Working Voltage: DC5.0V±5%
Maximum Current: 395 mA
Battery Capacity: 2000MAH
Charging Time: 5-7 hours

Decoding Capability

Scan Angle: 34°V x 30°H (Nominal)
Depth of Field:

Code 128 60mm-200mm(10mil)
QR Code 160 bytes (paper) 40mm-120mm (10mil)
DM Code 100 bytes (paper) 50mm-140mm (15mil)
QR Code 18 bytes (screen) 50mm-250mm (10mil)

Decoding:

2D PDF417,QR Code (QR1/2, Microl,Data MatrixECC200.ECC000.050.080.100.140).Chinese sensibleCode, etc..
1D Code128.UCC/EAN-128 AIM128.EAN-8.EAN-13ISBN/ISSN.UPC-E.UPC-AInterleawed 2 of 5.ITF-5,ITF-4Matrix 2 of 5. lndustrial 25 Standard 25 Code39.Codabar Code 93. Code 11 etc..

Prompting Mode: 1. Buzzer 2. LED Indicator Light 3.Vibration
Scan Mode (Hand-held): 1. Trigger Mode 2. Continuous Mode 3. Auto Sense Mode 4. Others
Charging Interface: USB
Measure: L*W*H(mm) 205*73*110mm
Weight: 170g
Cable: 1.5m
Color: Blue
IP Rating: IP54
Shock Resistance: 1 Meter High Free Fall

Packing List:

Scanner with USB Cable × 1
User's guide × 1
